Kx23 Air-Assist Airless & Airless Fluid Hose – 3/16″ Id, 3500 Psi

Description

The KX23 Series Safety Flex High Pressure Paint (Fluid) Hose is blue in color and offers a 3/16” I.D. with a polyamide Nylon® core, two ply polyester textile fiber braid with a polyurethane cover and stainless steel ¼” NPS (F) swivel fittings with spring guards.  The KX23 hose inner core is resistant to most of the solvents used in the air-assist airless (AAA) and airless paint industries. The cover is made of polyurethane for excellent flex fatigue and abrasion resistance. The KX23 fluid hose is manufactured to meet special requirements and specifications, especially recommended for use with all types of air-assist airless (AAA) and airless spray equipment.  This fluid hose directly replaces the 53-402-15 (15 ft), 53-402 (25 ft), 53-402-35 (35 ft) & 53-402-50 (50 ft) fluid hose for the C.A. Technologies 14:1 AAA pump systems.

Specifications:

• 15’, 25’,35’ & 50’ hose lengths available
• 3/16” inside diameter (I.D.) fluid hose (blue) – max pressure rating 3,500 psi
• ¼” NPS (F) fluid fitting – (stainless steel swivel fitting crimped permanently to the hose)
• Spring guards – (stainless steel)
• Polyamide nylon core
• Polyester textile fiber braid
• Polyurethane cover
• 10.4 mm hose outside diameter (O.D.)
• 14,000 psi (minimum burst psi)
• 40 mm (minimum bend)
• -40 to 200 degrees F (temperature range)
• Directly replaces the C.A. Technologies 53-402 Air-Assist Airless (AAA) fluid hose that is provided with the Cougar 14:1 pump package and the H20 14:1 pump packages.

Additional Properties:

• Safety thermoplastic hose to work at higher operating pressures
• Excellent resistance to paints, solvents & chemicals
• Excellent flexibility, flexfatigue & non kinking
• Abrasion & ozone resistant cover
• Superior electrostatic-grounding
• Small bend radius & very light weight
• Excellent volumetric expansion capability

Information:

KX23 Series Fluid Hose – Data Sheet

Please note that the KX23 series fluid hose is recommended for air-assist airless (AAA) and airless applications.  To purchase protective anti-static hose sleeve, please reference S-6607-1 to purchase by the foot or S-6607 to purchase a roll.
